Solar Powered and Diesel-Powered Lighting Tower
The Cahill Hybrid LT is a solar-powered light tower combined with a Kubota Diesel powered DC Generator. With an extremely low fuel consumption, the Cahill Light Tower will run up to 35 days before refueling. The Cahill Light Tower also requires fewer refuelling visits and oil changes than a conventional light tower, leading to lower operational costs and uptime. The DSE 3G web interface + GPS module allows for real-time remote monitoring and operation.
Contact Us
Inquires will be replied to within 24 hours.
Product Specifications & Applications
Specifications
Applications
Specifications
Lights: 4 x 100 W at 68,000 lumen each
Engine: 12.7 HP, 2-cylinder diesel
Fuel Consumption: 2.27 lph or 0.6 gph
Tank Capacity: 120 Litre or 31.7 gallons
Spill containment: 120%
Noise level: Less than 80 decibels
Construction Material: Galvanized steel
Mast Height: 7.8 m (approximately)
Weight: 820Kg trailer with parking-brake
Dimensions: 9′ 2″(L) x 4′ 5″(W)x 7’10” (H)
Engine: 12.7 HP, 2-cylinder diesel
Fuel Consumption: 2.27 lph or 0.6 gph
Tank Capacity: 120 Litre or 31.7 gallons
Spill containment: 120%
Noise level: Less than 80 decibels
Construction Material: Galvanized steel
Mast Height: 7.8 m (approximately)
Weight: 820Kg trailer with parking-brake
Dimensions: 9′ 2″(L) x 4′ 5″(W)x 7’10” (H)
Applications
Construction Lighting
Gas, oil and mining operations (explosion safe)
Yard and work site lighting
Lighting for rural and hard-to-reach areas
Gas, oil and mining operations (explosion safe)
Yard and work site lighting
Lighting for rural and hard-to-reach areas
Product Features
- Hybrid technology combines solar power and DC Generator
- Virtually no CO2 emission
- Eco-friendly integral spill containment (120%)
- Less than 80 decibels with generator running
- LED12V/24V tail-lights EC/DOT approved
- 6 – 8 hours of LED operation on battery bank only
- Galvanized steel MIG welded trailer construction
- Compact design is easily maneuverable during transport and takes up less space when stored
- 4 outriggers with stabilizing jacks
- DSE 3G web interface + GPS module for real-time remote monitoring and operation
- Winter package (diesel heater for coolant)
- Emergency stop switch mounted on outside
- Overspeed air intake D-valve + spark arrestor (oil & gas, mining specs)
- Automatic day/night sensors for efficient operation
- Block heater plug 110Vac 400Watt 30mm plug Kubota
- Battery isolator switch + Lockable cover mounted on outside
- Starter isolator switch + Lockable cover mounted on outside
