Patented Heat Technology
The CH12MS uses the same patented heat generating technology as the CH15MS but is designed for smaller jobs, providing heat with significant fuel savings over its competition.
The CH12MS has three different heat outputs (low, medium, and high) and consumes between 2.6 and 3.5 gph of diesel. The CH12MS features a 5400 Lumens – 60 Watts light tower with an inverter for external power requirements.
Contact Us
Inquires will be replied to within 24 hours.



Product Specifications & Applications
Specifications
Applications
Specifications
Output Duct: One 16″ Output
Fuel Consumption: 2.6 GPH – 3.5 GPH
Fuel: ULSD
Fuel Capacity: 120 Gallons – 34 to 48 hours run time
Engine: Perkins 60 HP
CFM: Up to 4200
Air Recirculation Package
Built-in AC Power
Three Different Heat Output Settings
Maintenance: Only regular maintenance is on the engine every 1500 hours
Service: All service on the ground with both feet on the ground – 14 gallons of extra oil, for prolonged oil changes, less maintenance equals fewer spills
Static Pressure: 7′ above the water column
10 LB Fire Extinguisher
Fuel Consumption: 2.6 GPH – 3.5 GPH
Fuel: ULSD
Fuel Capacity: 120 Gallons – 34 to 48 hours run time
Engine: Perkins 60 HP
CFM: Up to 4200
Air Recirculation Package
Built-in AC Power
Three Different Heat Output Settings
Maintenance: Only regular maintenance is on the engine every 1500 hours
Service: All service on the ground with both feet on the ground – 14 gallons of extra oil, for prolonged oil changes, less maintenance equals fewer spills
Static Pressure: 7′ above the water column
10 LB Fire Extinguisher
Applications
Temporary Site Heating
Equipment Startup
Heating BOP’s, Wellheads
Frost Prevention System
Gas Compressor Sites
Concrete Curing
New Building Construction
Steam-Line Pre-Heating
Pipeline Pre-Expansion
Thermal Conditioning
Tank, Vessel Coat Curing
Plant Start-up, Turnarounds
Flood Clean-up
Pipeline Heating, Drying
Equipment Startup
Heating BOP’s, Wellheads
Frost Prevention System
Gas Compressor Sites
Concrete Curing
New Building Construction
Steam-Line Pre-Heating
Pipeline Pre-Expansion
Thermal Conditioning
Tank, Vessel Coat Curing
Plant Start-up, Turnarounds
Flood Clean-up
Pipeline Heating, Drying
